Chapter 4 System Operation and Configuration
Output Relay 0 Communication Fault Value (Parameter 307)
Output Relay 0 Communication Fault Value (Parameter 307) defines which state
Output Relay 0 should go to when a communication fault occurs.
Table 74 - Output Relay 0 Communication Fault Value (Parameter 307)
Output Relay 0 Final Fault Value (Parameter 562)
Output Relay 0 Final Fault Value (Parameter 562) is available in E300 relay
firmware v5.000 and higher. This parameter defines which state Output Relay 0
should go to when communication is not restored with the time defined in Fault
Mode Output State Duration (Parameter 561).
Table 75 - Output Relay 0 Final Fault Value (Parameter 562)
Output Relay 1 Communication Fault Action (Parameter 312)
Output Relay 1 Communication Fault Action (Parameter 312) defines how
Output Relay 1 responds when a communication fault occurs when this
parameter is assigned as a Normal/General Purpose Relay or Control/Control &
Trip R el a y.
Table 76 - Output Relay 1 Communication Fault Action (Parameter 312)
Output Relay 1 Communication Fault Value (Parameter 313)
Output Relay 1 Communication Fault Value (Parameter 313) defines which state
Output Relay 1 should go to when a communication fault occurs.
Table 77 - Output Relay 1 Communication Fault Value (Parameter 313)
Output Relay 1 Final Fault Value (Parameter 563)
Output Relay 1 Final Fault Value (Parameter 563) is available in E300 relay
firmware v5.000 and higher. This parameter defines which state Output Relay 1
Value Assignment Description
0Open Open Output Relay 0
1 Closed Close Output Relay 0
Value Assignment Description
0Open Open Output Relay 0
1 Closed Close Output Relay 0
Value Assignment Description
0 GoToCommFltValue Set to Output Relay 1 Communication Fault Value (Parameter 313)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0Open Open Output Relay 1
1 Closed Close Output Relay 1

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
