Rockwell Automation Publication 193-UM015E-EN-P - October 2015 103
System Operation and Configuration Chapter 4
should go to when communication is not restored with the time defined in Fault
Mode Output State Duration (Parameter 561).
Table 78 - Output Relay 1 Final Fault Value (Parameter 563)
Output Relay 2 Communication Fault Action (Parameter 317)
Output Relay 2 Communication Fault Action (Parameter 317) defines how
Output Relay 2 responds when a communication fault occurs when this
parameter is assigned as a Normal/General Purpose Relay or Control/Control &
Trip R el a y.
Table 79 - Output Relay 2 Communication Fault Action (Parameter 318)
Output Relay 2 Communication Fault Value (Parameter 319)
Output Relay 2 Communication Fault Value (Parameter 319) defines which state
Output Relay 2 should go to when a communication fault occurs.
Table 80 - Output Relay 2 Communication Fault Value (Parameter 319)
Output Relay 2 Final Fault Value (Parameter 564)
Output Relay 2 Final Fault Value (Parameter 564) is available in E300 relay
firmware v5.000 and higher. This parameter defines which state Output Relay 2
should go to when communication is not restored with the time defined in Fault
Mode Output State Duration (Parameter 561).
Table 81 - Output Relay 2 Final Fault Value (Parameter 564)
Digital Expansion Module 1 Output Relay Communication Fault Action (Parameter 324)
Digital Expansion Module 1 Output Relay Communication Fault Action
(Parameter 324) defines how both output relays on Digital Expansion Module 1
responds when a communication fault occurs.
Value Assignment Description
0Open Open Output Relay 1
1 Closed Close Output Relay 1
Value Assignment Description
0 GoToCommFltValue Set to Output Relay 2 Communication Fault Value (Parameter 319)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0Open Open Output Relay 2
1 Closed Close Output Relay 2
Value Assignment Description
0Open Open Output Relay 2
1 Closed Close Output Relay 2
