104 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 4 System Operation and Configuration
Table 82 - Digital Expansion Module 1 Output Relay Communication Fault Action (Parameter 324)
Digital Expansion Module 1 Output Relay Communication Fault Value (Parameter 325)
Digital Expansion Module 1 Output Relay Communication Fault Value
(Parameter 325) defines which state both output relays should go to when a
communication fault occurs.
Table 83 - Digital Expansion Module 1 Output Relay Communication Fault Value (Parameter 325)
Digital Expansion Module 1 Output Relay Final Fault Value (Parameter 565)
Digital Expansion Module 1 Output Relay Final Fault Value (Parameter 565) is
available in E300 relay firmware v5.000 and higher. This parameter defines which
state both output relays should go to when communication is not restored with
the time defined in Fault Mode Output State Duration (Parameter 561).
Table 84 - Digital Expansion Module 1 Output Relay Final Fault Value (Parameter 565)
Digital Expansion Module 2 Output Relay Communication Fault Action (Parameter 330)
Digital Expansion Module 2 Output Relay Communication Fault Action
(Parameter 330) defines how both output relays on Digital Expansion Module 2
responds when a communication fault occurs.
Table 85 - Digital Expansion Module 2 Output Relay Communication Fault Action (Parameter 330)
Digital Expansion Module 2 Output Relay Communication Fault Value (Parameter 331)
Digital Expansion Module 2 Output Relay Communication Fault Value
(Parameter 331) defines which state both output relays should go to when a
communication fault occurs.
Value Assignment Description
0GoToCommFltValue
Set to Digital Expansion Module 1 Output Relay Communication Fault
Value (Parameter 325)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
Value Assignment Description
0 Open Open Digital Expansion Module 1 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 1 Output Relay 0 and Output Relay 1
Value Assignment Description
0 Open Open Digital Expansion Module 1 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 1 Output Relay 0 and Output Relay 1
Value Assignment Description
0GoToCommFltValue
Set to Digital Expansion Module 2 Output Relay Communication Fault
Value (Parameter 331)
1 HoldLastState Hold the last commanded state from the network or DeviceLogix
