142 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 4 System Operation and Configuration
Analog Module 3 – Input Channel 02 Filter Frequency
Analog Module 3 – Input Channel 02 Filter Frequency (Parameter 520) defines
update rate for the input channels of the analog module.
Table 189 - Analog Module 3 – Input Channel 02 Filter Frequency (Parameter 520)
Analog Module 3 – Input Channel 02 Open Circuit State
Analog Module 3 – Input Channel 02 Open Circuit State (Parameter 521)
defines what the input channel reports when the input channel has an open
circuit. Open circuit detection is always enabled for this input channel.
Table 190 - Analog Module 3 – Input Channel 02 Open Circuit State (Parameter 521)
Analog Module 3 – Input Channel 02 RTD Type Enable
Analog Module 3 – Input Channel 02 RTD Type Enable (Parameter 522)
defines the type of RTD to monitor when the input channel type is configured to
scan an RTD sensor.
Table 191 - Analog Module 3 – Input Channel 02 RTD Type Enable (Parameter 522)
Analog Module 3 – Output Channel 00 Type
Analog Module 3 – Output Channel 00 Type (Parameter 526) defines the type
of analog signal that Output Channel 00 of Analog Module 3 provides.
Table 192 - Analog Module 3 – Output Channel 00 Type (Parameter 526)
Value Assignment Description
0 17 Hz Analog to Digital Conversion Update Frequency of 17 Hz
1 4 Hz Analog to Digital Conversion Update Frequency of 4 Hz
2 62 Hz Analog to Digital Conversion Update Frequency of 62 Hz
3 470 Hz Analog to Digital Conversion Update Frequency of 470 Hz
Value Assignment Description
0 Upscale Reports the high limit of the input channel type
1 Downscale Reports the low limit of the input channel type
2 Zero Reports zero
Value Assignment Description
0 3-Wire Scan a 3-wire RTD sensor
1 2-Wire Scan a 2-wire RTD sensor
Value Assignment Description
0 Disabled Disable the analog input
1 4To20mA Provide an analog current signal from 4…20 mA
2 0To20mA Provide an analog current signal from 0…20 mA
3 0To10Volts Provide an analog voltage signal from 0…10 V DC
4 1To5Volts Provide an analog voltage signal from 1…5 V DC
5 0To5Volts Provide an analog voltage signal from 0…5 V DC
