Chapter 5 Operating Modes
Both LogicDefinedPt00Data and LogicDefinedPt01Data are maintained values,
so the reversing starter remains energized when LogicDefinedPt00Data or
LogicDefinedPt01Data has a value of 1. You can program the appropriate state of
the starter when communication is lost using the Network Communication Fault
and Network Communication Idle parameters (Parameters 569 – 573) described
in Chapter 4
.
In Local control mode, the E300 Operator Station’s “I” key is used to control
Output Relay 0, which controls the forward contactor coil. The “II” key controls
Output Relay 1, which controls the reversing contactor coil. The “0” key is used
to de-energize Output Relay 0 and Output Relay 1. These keys are momentary
push buttons, so the reversing starter remains energized when you release the “I”
or “II” button. The “0” button must be pressed before changing to another
direction.
To change between Local and Remote control mode press and release the “Local/
Remote” button on the E300 Operator Station. The LED above “Local/Remote”
button illuminates yellow in Local control mode and red in Remote control
mode.
InterlockDelay (Parameter 215) defines the minimum time delay when switching
direction.
The E300 issues a trip or warning event if the E300 Operator Station disconnects
from the base relay.
The reset button of the E300 Operator Station is enabled for this operating
mode.
Rules
1. Available for Control Module firmware v5.000 and higher.
2. Output Pt00 Assignment (Parameters 202) must be set to Control Relay.
3. Output Pt01 Assignment (Parameters 203) must be set to Control Relay.
4. Overload Trip must be enabled in TripEnableI (Parameter 183).
5. Operator Station Trip must be disabled in TripEnableC (Parameter 186).
6. Operator Station Option Match Trip or Warning must be enabled.
• Option Match Trip or must be enabled in TripEnableC (Parameter
186)
• Operator Station must be enabled in Mismatch Action (Parameter
233)
IMPORTANT
The Reversing Starter (Network & Operator Station) operating mode uses the
value in network tag LogicDefinedPt00Data to control the starter. When
communication is restored between an automation controller and the E300,
the starter energizes if the value in LogicDefinedPt00Data or
LogicDefinedPt01Data is set to 1.

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
