Allen-Bradley E300 User Manual

416 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
Table 355 - Under Power Factor Lagging Warn Level (Parameter 413)
Over Power Factor Lagging Trip
The E300 relay trips with an Over Power Factor Lagging indication if:
• No trip currently exists
• Over Power Factor Lagging Trip is enabled
• Current is present
• Voltage is present
• Over Power Factor Lagging Inhibit Time has expired
• The total power factor lagging is greater than the Over Power Factor
La
gg
ing Trip Level for a time period greater than the Over Power Factor
Lagging Trip Delay.
If the E300 relay trips on an over power factor lagging, the:
• TRIP/WARN LED status indicator flashes a red 2-long / 10-short blink
patter
n
• Bit 9 in Power Trip Status (Parameter 6) sets to 1
• Bit 0 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Trip Relay open
• Any relay outputs configured as a Control Relay open
• Any relay outputs configured as a Trip Alarm close
• Any relay outputs configured as a Normal Relay are placed in their
P
r
ote
ction Fault state (if so programmed)
Default Value -95
Minimum Value -100
Maximum Value 0
Parameter Type SINT
Size (Bytes) 1
Scaling Factor 1
Units %
IMPORTANT
The Under Power Factor Lagging Warning function does not include a time
delay feature. Once the Under Power Factor Lagging Inhibit Time has expired,
the Under Power Factor Lagging Warning indication is instantaneous.

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
