Rockwell Automation Publication 193-UM015E-EN-P - October 2015 417
Protective Trip and Warning Functions Chapter 6
Over Power Factor Lagging Trip Delay
Over Power Factor Lagging Trip Delay (Parameter 415) allows you to define the
time period an over power factor lagging condition must be present before a trip
occurs. It is adjustable from 0.1…25.0 seconds.
Table 356 - Over Power Factor Lagging Trip Delay (Parameter 415)
Over Power Factor Lagging Trip Level
Over Power Factor Lagging Trip Level (Parameter 416) allows you to define the
total power factor lagging at which the E300 relay trips on over power factor
lagging. It is user-adjustable from 0…2,000,000 kW.
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
• Output PT00 Protection Fault Action (Parameter 304)
• Output PT00 Protection Fault Value (Parameter 305)
• Output PT01 Protection Fault Action (Parameter 310)
• Output PT01 Protection Fault Value (Parameter 311)
• Output PT02 Protection Fault Action (Parameter 316)
• Output PT02 Protection Fault Value (Parameter 317)
• Output Digital Module 1 Protection Fault Action (Parameter 322)
• Output Digital Module 1 Protection Fault Value (Parameter 323)
• Output Digital Module 2 Protection Fault Action (Parameter 328)
• Output Digital Module 2 Protection Fault Value (Parameter 329)
• Output Digital Module 3 Protection Fault Action (Parameter 334)
• Output Digital Module 3 Protection Fault Value (Parameter 335)
• Output Digital Module 4 Protection Fault Action (Parameter 340)
• Output Digital Module 4 Protection Fault Value (Parameter 342)
Default Value 1.0
Minimum Value 0.1
Maximum Value 25.0
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 10
Units Seconds
