Protective Trip and Warning Functions Chapter 6
Under Power Factor Leading Trip
The E300 relay trips with an Under Power Factor Leading indication if:
• No trip currently exists
• Under Power Factor Leading Trip is enabled
• Current is present
• Voltage is present
• Under Power Factor Leading Inhibit Time has expired
• The total power factor leading is less than the Under Power Factor Leading
T
rip
Level for a time period greater than the Under Power Factor Leading
Trip D elay.
If the E300 relay trips on an under power factor leading, the:
• TRIP/WARN LED status indicator flashes a red 2-long / 11-short blink
patter
n
• B
it 10 in Power Trip Status (Parameter 6) sets to 1
• Bit 0 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Trip Relay open
• Any relay outputs configured as a Control Relay open
• Any relay outputs configured as a Trip Alarm close
• Any relay outputs configured as a Normal Relay are placed in their
Prote
ction Fault state (if so programmed)
IMPORTANT
The Over Power Factor Lagging Warning function does not include a time delay
feature. Once the Over Power Factor Lagging Inhibit Time has expired, the Over
Power Factor Lagging Warning indication is instantaneous.

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
