Allen-Bradley E300 User Manual

44 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 2 Installation and Wiring
Figure 29 - E300 Sensing Module 193-ESM-___-100A-E3T
Figure 30 - E300 Sensing Module 193-ESM-___-200A-T
Figure 31 - E300 Sensing Module 193-ESM-___-200A-T with Terminal Covers
71.6
(2.82)
41.2
(1.62)
41.4
(1.63)
139.9
(5.51)
141.5
(5.57)
17.7
(0.70)
4.05
(0.16)
76.6
(3.02)
60
(2.36)
130
(5.12)
5.5
(0.22)
q
119.8
(4.72)
39
(1.54)
135.7
(5.34)
22
(0.86)
63.9
(2.51)
42.6
(1.68)
151.4
(5.96)
105
(4.13)
(105)
93
(3.66)
n 5.5
(0.22)
FROM
MTG. HOLE
FROM
MTG. HOLE
M8
119.8
(4.72)
211
(8.32)
151.4
(5.96)
105
(4.13)
93
(3.66)
n 5.5
(0.22)
22
(0.86)
63.9
(2.51)
FROM
MTG. HOLE
FROM
MTG. HOLE

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
