Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 475
Protective Trip and Warning Functions Chapter 6
Analog Module 4 – Channel 02 Warning Level
Analog Module 4 – Channel 02 Warning Level (Parameter 556) allows you to
define the magnitude of the analog signal in which the E300 relay trips on an
Analog Module 4 – Channel 02 Over Level warning. It is user-adjustable from
-32768…+32767.
Table 416 - Analog Module 4 – Channel 02 Warning Level (Parameter 556)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
