540 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
15 L2 Current Lost for longer than the L2 Loss Trip Delay
16 L3 Current Lost for longer than the L3 Loss Trip Delay
17 Line to Line Under-Voltage condition detected
18 Line to Line Over-Voltage condition detected
19 Phase to phase voltage imbalance detected
20 The unit detects the supply voltage phases are rotated
21 Line voltage frequency is below trip level
22 Line voltage frequency has exceeded trip level
25 Sensing Module boot loader failed to load firmware
26 Sensing Module output enable open
27 Sensing Module missing interrupts
28 Sensing Module not calibrated
29 Sensing Module frame type failure
30 Sensing Module flash configuration failure
31 Sensing Module detected an overrun error
32 Sensing Module is not responding
33 Total Real Power (kW) is below trip level
34 Total Real Power (kW) has exceeded trip level
35 Under Total Reactive Power Consumed (+kVAR) condition detected
36 Over Total Reactive Power Consumed (+kVAR) condition detected
37 Under Total Reactive Power Generated (-kVAR) condition detected
38 Over Total Reactive Power Generated (-kVAR) condition detected
39 Total Apparent Power (VA or kVA or MVA) is below trip level
40 Total Apparent Power (VA or kVA or MVA) exceeded trip level
41 Under Total Power Factor Lagging (-PF) condition detected
42 Over Total Power Factor Lagging (-PF) condition detected
43 Under Total Power Factor Leading (+PF) condition detected
44 Over Total Power Factor Leading (+PF) condition detected
49 Test trip caused by holding the Test/Reset button for 2 seconds
50 PTC input indicates that the motor stator windings overheated
51 DeviceLogix defined trip was generated
52 The Stop button the Operator Station was pressed
53 Remote trip command detected
54 Maximum starts per hour exceeded
55 Hardware configuration fault. Check for shorts on input terminal
56 Invalid parameter config. See parameters 38-39 for details
58 DeviceLogix Feedback Timeout Trip was detected
59 Control Module CAN0 initialization failure
60 Control Module CAN0 bus failure
61 Control Module CAN1 initialization failure
62 Control Module CAN1 bus failure
63 Control Module ADC0 failure
64 Control Module detected too many CRC errors
65 Input Channel 00 on Analog Module 1 exceeded its Trip Level
66 Input Channel 01 on Analog Module 1 exceeded its Trip Level
67 Input Channel 02 on Analog Module 1 exceeded its Trip Level
68 Input Channel 00 on Analog Module 2 exceeded its Trip Level
69 Input Channel 01 on Analog Module 2 exceeded its Trip Level
70 Input Channel 02 on Analog Module 2 exceeded its Trip Level
71 Input Channel 00 on Analog Module 3 exceeded its Trip Level
Trip History Code Description
