Rockwell Automation Publication 193-UM015E-EN-P - October 2015 541
Metering and Diagnostics Chapter 8
Trip History 0
Trip History 0 (Parameter 127) reports the most recent trip event.
Trip History 1
Trip History 1 (Parameter 128) reports the second most recent trip event.
72 Input Channel 01 on Analog Module 3 exceeded its Trip Level
73 Input Channel 02 on Analog Module 3 exceeded its Trip Level
74 Input Channel 00 on Analog Module 4 exceeded its Trip Level
75 Input Channel 01 on Analog Module 4 exceeded its Trip Level
76 Input Channel 02 on Analog Module 4 exceeded its Trip Level
77 External NVS Chip has detected communication timeout error
78 External NVS Chip has detected a CRC error
79 External NVS Chip has detected data out of range
81 Digital Expansion Module 1 is not operating properly
82 Digital Expansion Module 2 is not operating properly
83 Digital Expansion Module 3 is not operating properly
84 Digital Expansion Module 4 is not operating properly
85 Analog Expansion Module 1 is not operating properly
86 Analog Expansion Module 2 is not operating properly
87 Analog Expansion Module 3 is not operating properly
88 Analog Expansion Module 4 is not operating properly
90 Control Module installed does not match the expected type
91 Sensing Module installed does not match the expected type
92 Comms Module installed does not match the expected type
93 Operator Station installed does not match expected type
94 Digital Module installed does not match the expected type
95 Analog Module installed does not match the expected type
96 Test Mode is engaged and current/voltage was detected
97 Heap memory could not be allocated
98 Vendor ID hardware fault
Trip History 0 (Parameter 127)
Default Value 0
Minimum Value 0
Maximum Value 99
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units
Trip History 1 (Parameter 128)
Default Value 0
Minimum Value 0
Maximum Value 99
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Trip History Code Description
