Allen-Bradley E300 User Manual

542 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Trip History 2
Trip History 2 (Parameter 129) reports the third most recent trip event.
Trip History 3
Trip History 3 (Parameter 130) reports the fourth most recent trip event.
Trip History 4
Trip History 4 (Parameter 131) reports the fifth most recent trip event.
Trip History Mask
You can decide which trip events are recorded into the E300 relay’s trip history by
using the Trip History Masks.
Current Trip History Mask
Current Trip History Mask (Parameter 139) allows you to select which current-
based trip events are recorded in the trip history.
Units 
Trip History 2 (Parameter 129)
Default Value 0
Minimum Value 0
Maximum Value 99
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
Trip History 3 (Parameter 130)
Default Value 0
Minimum Value 0
Maximum Value 99
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
Trip History 4 (Parameter 131)
Default Value 0
Minimum Value 0
Maximum Value 99
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units 
