Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 543
Metering and Diagnostics Chapter 8
Table 542 - Current Trip History Mask (Parameter 139)
Voltage Trip History Mask
Voltage Trip History Mask (Parameter 140) allows you to select which voltage-
based trip events are recorded in the trip history.
Table 543 - Voltage Trip History Mask (Parameter 140)
Power Trip History Mask
Power Trip History Mask (Parameter 141) allows you to select which power-
based trip events are recorded in the trip history.
Bit
1514131211109876543210 Function
XOverload Trip
X Phase Loss Trip
X Ground Fault Trip
X Stall Trip
X Jam Trip
X Underload Trip
X Current Imbalance Trip
X L1 Under Current Trip
X L2 Under Current Trip
X L3 Under Current Trip
X L1 Over Current Trip
X L2 Over Current Trip
X L3 Over Current Trip
X L1 Line Loss Trip
X L2 Line Loss Trip
X L3 Line Loss Trip
Bit
1514131211109876543210 Function
XUnder Voltage Trip
X Over Voltage Trip
X Voltage Imbalance Trip
X Phase Rotation Trip
X Under Frequency Trip
X Over Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
