Allen-Bradley E300 User Manual

544 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Table 544 - Power Trip History Mask (Parameter 141)
Control Trip History Mask
Control Trip History Mask (Parameter 142) allows you to select which control-
based trip events are recorded in the trip history.
Table 545 - Control Trip History Mask (Parameter 142)
Analog Trip History Mask
Analog Trip History Mask (Parameter 143) allows you to select which analog-
based trip events are recorded in the trip history.
Bit
1514131211109876543210 Function
XUnder kW Trip
X Over kW Trip
X Under kVAR Consumed Trip
X Over kVAR Consumed Trip
X Under kVAR Generated Trip
X Over kVAR Generated Trip
X Under kVA Trip
X Over kVA Trip
X Under Power Factor Lagging Trip
X Over Power Factor Lagging Trip
X Under Power Factor Leading Trip
X Over Power Factor Leading Trip
Reserved
Reserved
Reserved
Reserved
Bit
1514131211109876543210 Function
XTest Trip
X PTC Trip
X DeviceLogix Trip
X Operator Station Trip
X Remote Trip
X Blocked Start Trip
X Hardware Fault Trip
X Configuration Trip
X Option Match Trip
X Feedback Timeout Trip
X Expansion Bus Trip
Reserved
Reserved
X Nonvolatile Memory Trip
X Test Mode Trip
Reserved

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
