Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 549
Metering and Diagnostics Chapter 8
Table 548 - Current Warning History Mask (Parameter 145)
Voltage Warning History Mask
Voltage Warning History Mask (Parameter 146) allows you to select which
voltage-based warning events are recorded in the warning history.
Table 549 - Voltage Warning History Mask (Parameter 146)
Power Warning History Mask
Power Warning History Mask (Parameter 147) allows you to select which power-
based warning events are recorded in the warning history.
Bit
1514131211109876543210 Function
XOverload Warning
Reserved
X Ground Fault Warning
Reserved
X Jam Warning
X Underload Warning
X Current Imbalance Warning
X L1 Under Current Trip
X L2 Under Current Trip
X L3 Under Current Trip
X L1 Over Current Trip
X L2 Over Current Trip
X L3 Over Current Trip
X L1 Line Loss Trip
X L2 Line Loss Trip
X L3 Line Loss Trip
Bit
1514131211109876543210 Function
X
Under Voltage Warning
X Over Voltage Warning
X Voltage Imbalance Warning
X Phase Rotation Warning
X Under Frequency Warning
X Over Frequency Warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
