Allen-Bradley E300 User Manual

550 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Table 550 - Power Warning History Mask (Parameter 147)
Control Warning History Mask
Control Warning History Mask (Parameter 148) allows you to select which
control-based warning events are recorded in the warning history.
Table 551 - Control Warning History Mask (Parameter 148)
Analog Warning History Mask
Analog Warning History Mask (Parameter 149) allows you to select which
control-based warning events are recorded in the warning history.
Bit
1514131211109876543210 Function
XUnder kW Warning
X Over kW Warning
X Under kVAR Consumed Warning
X Over kVAR Consumed Warning
X Under kVAR Generated Warning
X Over kVAR Generated Warning
X Under kVA Warning
X Over kVA Warning
X Under Power Factor Lagging Warning
X Over Power Factor Lagging Warning
X Under Power Factor Leading Warning
X Over Power Factor Leading Warning
Reserved
Reserved
Reserved
Reserved
Bit
1514131211109876543210 Function
Reserved
X PTC Warning
X DeviceLogix Warning
Reserved
Reserved
Reserved
Reserved
Reserved
X Option Match Warning
X Feedback Timeout Warning
X Expansion Bus Warning
X Number Of Starts Warning
X Operating Hours Warning
Reserved
Reserved
Reserved

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
