Rockwell Automation Publication 193-UM015E-EN-P - October 2015 57
Installation and Wiring Chapter 2
Table 10 - Short Circuit Ratings per EN60947-4-1
592-ESM-___-30A-S2 500_-A_ 18 5000 600 100 100
500_-B_ 27
592-ESM-___-60A-S2 500_-C_ 45 175 175
193-ESM-___-100A-P — — 10,000 600 400 400
193-ESM-___-100A-T
193-ESM-___-100A-E3T
193-ESM-___-100A-C97 100-C60 60 350 350
100-C72 72
100-C85 85
100-C97 97
592-ESM-___-100A-S3 500_-D_ 90 350 350
193-ESM-___-200A-P — — 600 600
193-ESM-___-200A-T
193-ESM-___-200A-D180 100-D115 115 300 250
100-D140 140
100-D180 180
592-ESM-___-200A-S4 500_-E_ 135 400 175
Sensing Module Cat. No. Contactor Cat. No. Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage [V AC]
Max. RKs non-time
Delay Fuse Size [A]
Max. Listed Circuit
Breaker Size [A]
Overload Relay with Sensing Module Cat. No. Prospective Short-
Circuit Current, I
r
[A]
Conditional Short-Circuit
Current, I
q
[A]
Maximum Voltage [V]
193-ESM-___-30A-C23 3,000 100,000 690
193-ESM-___-30A-C55
193-ESM-___-30A-E3T
592-ESM-___-30A-S2
193-ESM-___-60A-C55
193-ESM-___-60A-E3T
592-ESM-___-60A-S2
193-ESM-___-30A-T
193-ESM-___-60A-T
193-ESM-___-30A-P
193-ESM-___-60A-P
193-ESM-VIG-30A-CT
193-ESM-___-100A-C97 5,000 100,000 690
193-ESM-___-100A-E3T
193-ESM-___-100A-P
193-ESM-___-100A-T
592-ESM-___-100A-S3
193-ESM-___-200A-D180 10,000 100,000 690
193-ESM-___-200A-P
193-ESM-___-200A-T
592-ESM-___-200A-S4
