58 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 2 Installation and Wiring
Table 11 - High Fault Short Circuit Ratings Using Standalone Overload Relays When Protected by
Fuses per UL60947-4-1 and CSA 22.2 No. EN60947-4-1
Table 12 - High Fault Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with
Bul. 100-C and 100-D IEC contactors that are protected by fuses
Sensing Module Cat. No.
Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage [V] Class J or CC Fuse [A]
193-ESM-___-30A-P 30 100,000 600 60
193-ESM-VIG-30A-CT
193-ESM-___-30A-T
193-ESM-___-30A-E3T
193-ESM-___-60A-P 60 100,000 600 100
193-ESM-___-60A-T
193-ESM-___-60A-E3T
193-ESM-___-100A-P 100 100,000 600 225
193-ESM-___-100A-T
193-ESM-___-100A-E3T
193-ESM-___-200A-P 200 100,000 600 400
193-ESM-___-200A-T
Sensing Module Cat. No.
Contactor Cat. No. Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage [V] Class J or CC Fuse [A]
193-ESM-___-30A-C23 100-C09 9 100,000 600 20
100-C12 12 20
100-C16 16 30
100-C23 23 30
193-ESM-___-30A-C55,
193-ESM-___-60A-C55
100-C30 30 50
100-C37 37 50
100-C43 43 70
100-C55 55 80
193-ESM-___-100A-C97 100-C60 60 80
100-C72 72 100
100-C85 85 150
100-C97 97 200
193-ESM-___-200A-D180 100-D115 115 200
100-D140 140 250
100-D180 180 300
