Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 59
Installation and Wiring Chapter 2
Table 13 - Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with Bul. 100-C IEC
contactors that are protected by Bul. 140U-D circuit breakers
Table 14 - High Fault Short Circuit Ratings using Bul. 140MG Circuit Protectors per UL60947-4-1
and CSA 22.2 No. EN60947-4-1
Overload Relay with
Sensing Module Cat. No.
Contactor Cat. No. Max. Starter FLC[A]
Max. Available Fault
Current [A]
Max. Voltage [V]
Max. Circuit Breaker
Cat. No. 140U-D6D3-
193-ESM-___-30A-C23 100-C09 9 65,000 480Y/277V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C23 100-C09 9 35,000 600Y/347V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C23 100-C09 9 5,000 600Y/347V C30 (30 A)
100-C12 12
100-C16 16
100-C23 23
Sensing Module Cat.
No.
Contactor Cat.
No.
Max. Starter
FLC [A]
Max. Available Fault Current [kA]
Circuit Protector Cat.
No.
Max. Circuit
Protector Current [A]
Min. Enclosure Size
[in.]
480V AC 600V AC
193-ESM-___-30A-C55 100-C30 30 65 25 140MG-H8P-C50 50 24 x 20 x 8 with two
hinges and two multi-turn
screw-type latches
193-ESM-___-60A-C55 100-C37 37 140MG-H8P-C50 50
100-C43 43 140MG-H8P-C50 50
100-C55 55 140MG-H8P-C80 80
193-ESM-___-100A-
C97
100-C60 60 140MG-H8P-D12 125 24 x 20 x 8 with two
hinges and two multi-turn
screw-type latches
100-C72 72 140MG-H8P-D12 125
100-C85 85 140MG-H8P-D12 125
100-C97 97 140MG-H8P-D12 125

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
