60 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 2 Installation and Wiring
Table 15 - High Fault Short Circuit Ratings using listed Circuit Breakers per UL60947-4-1
and CSA 22.2 No. EN60947-4-1
Table 16 - High Fault Short Circuit Ratings using Bul. 140G circuit breakers per UL60947-4-1 and
CSA 22.2 No. EN60947-4-1
Table 17 - High Fault Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with
Bul. 500 line NEMA contactors that are protected by fuses
Sensing Module Cat. No. Contactor Cat. No. Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage [V AC]
Max. Listed Circuit
Breaker Size [A]
Min. Enclosure
Volume [in
3
]
193-ESM-___-30A-P — — 100,000 600 100 1547
193-ESM-VIG-30A-CT
193-ESM-___-30A-T
193-ESM-___-30A-E3T
193-ESM-___-60A-P — —
193-ESM-___-60A-T
193-ESM-___-60A-E3T
193-ESM-___-30A-C23 100-C09 9
100-C12 12
100-C16 16
100-C23 23
193-ESM-___-30A-C55 100-C30 30
193-ESM-___-60A-C55 100-C37 37
100-C43 43
100-C55 55
592-ESM-___-30A-S2 500_-A_ 18 2142
500_-B_ 27
592-ESM-___-60A-S2 500_-C_ 45
Sensing Module Cat. No. Contactor Cat. No. Max. Starter FLC [A]
Max. Available Fault Current [kA]
Circuit Breaker Cat.
No.
Max. Circuit Breaker
Current [A]
480V 600V
193-ESM-___-100A-C97 100-C60 60 65 25 140G-J6_3-D25 250
100-C72 72
100-C85 85
100-C97 97
193-ESM-___-200A-D180 100-D115 115 65 25 140G-J6_3-D25 225
100-D140 140
100-D180 180
592-ESM-___-200A-S4 500_-E_ 135 22 14 140G-J6_3-D17 175
Overload Relay with Sensing Module
Cat. No.
Contactor Size Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage
[V]
Max. UL Fuse [A]
RJ
592-ESM-___-30A-S2 00 9 100,000 600 — 20
592-ESM-___-30A-S2 0 18 240 30 30
600 30 30
592-ESM-___-30A-S2 1 27 240 60 100
600 30 50
592-ESM-___-60A-S2 2 45 240 100 200
600 60 100
592-ESM-___-100A-S3 3 90 240 200 350
600 100 200
592-ESM-___-200A-S4 4 135 240 300 500
600 200 400
