Allen-Bradley E300 User Manual

640 Rockwell Automation Publication 193-UM015E-EN-P - November 2013
Appendix B Parameter List
Trip/Warn History
(continued)
141 TripHistoryMaskP C.History.UnderRealPowerTripEn
C.History.OverRealPowerTripEn
C.History.UnderReactivePowerConsumedTripEn
C.History.OverReactivePowerConsumedTripEn
C.History.UnderReactivePowerGeneratedTripEn
C.History.OverReactivePowerGeneratedTripEn
C.History.UnderApparentPowerTripEn
C.History.OverApparentPowerTripEn
C.History.UnderPowerFactorLaggingTripEn
C.History.OverPowerFactorLaggingTripEn
C.History.UnderPowerFactorLeadingTripEn
C.History.OverPowerFactorLeadingTripEn
Trip History Mask
for Power-based
Trips
UINT 2 1 Bit0= UnderKWTrip
Bit1= OverKWTrip
Bit2= UnderKVARConTrip
Bit3= OverKVARConTrip
Bit4= UnderKVARGenTrip
Bit5= OverKVARGenTrip
Bit6= UnderKVATrip
Bit7= OverKVATrip
Bit8= UnderPFLagTrip
Bit9= OverPFLagTrip
Bit10= UnderPFLeadTrip
Bit11= OverPFLeadTrip
0xFFF
142 TripHistoryMaskC C.History.TestTripEn
C.History.PTCTripEn
C.History.OperatorStationTripEn
C.History.RemoteTripEn
C.History.BlockedStartTripEn
C.History.HardwareFaultTripEn
C.History.ConfigurationTripEn
C.History.ModuleMismatchTripEn
C.History.ExpansionBusTripEn
C.History.NVMErrorTripEn
C.History.MCCTestPositionTripEn
Trip History Mask
for Control-based
Trips
UINT 2 1 Bit0= TestTrip
Bit1= PTCTrip
Bit2= DLXTrip
Bit3= OperStationTrip
Bit4= RemoteTrip
Bit5= BlockedStartTrip
Bit6= HardwareFltTrip
Bit7= ConfigTrip
Bit8= OptionMatchTrip
Bit9= DLXFBTimeoutTrip
Bit10= ExpansionBusTrip
Bit11= Reserved
Bit12= Reserved
Bit13= NVSTrip
Bit14=TestModeTrip
0x27FF
143 TripHistoryMaskA C.History.Analog1Ch00TripEn
C.History.Analog1Ch01TripEn
C.History.Analog1Ch02TripEn
C.History.Analog2Ch00TripEn
C.History.Analog2Ch01TripEn
C.History.Analog2Ch02TripEn
C.History.Analog3Ch00TripEn
C.History.Analog3Ch01TripEn
C.History.Analog3Ch02TripEn
C.History.Analog4Ch00TripEn
C.History.Analog4Ch01TripEn
C.History.Analog4Ch02TripEn
Trip History Mask
for Analog Input
Based Trips
UINT 2 1 Bit0= InAnMod1Ch00Trip
Bit1= InAnMod1Ch01Trip
Bit2= InAnMod1Ch02Trip
Bit3= InAnMod2Ch00Trip
Bit4= InAnMod2Ch01Trip
Bit5= InAnMod2Ch02Trip
Bit6= InAnMod3Ch00Trip
Bit7= InAnMod3Ch01Trip
Bit8= InAnMod3Ch02Trip
Bit9= InAnMod4Ch00Trip
Bit10= InAnMod4Ch01Trip
Bit11= InAnMod4Ch02Trip
0xFFF
144 Reserved
145 WarnHistoryMaskI C.History.OverloadWarningEn
C.History.GroundFaultCurrentWarningEn
C.History.JamWarningEn
C.History.UnderloadWarningEn
C.History.CurrentImbalanceWarningEn
C.History.L1UnderCurrentWarningEn
C.History.L2UnderCurrentWarningEn
C.History.L3UnderCurrentWarningEn
C.History.L1OverCurrentWarningEn
C.History.L2OverCurrentWarningEn
C.History.L3OverCurrentWarningEn
C.History.L1LineLossWarningEn
C.History.L2LineLossWarningEn
C.History.L3LineLossWarningEn
Warning History
Mask for Current-
based Warnings
UINT 2 1 Bit0= OverloadWarning
Bit1= Reserved
Bit2= GroundFltWarning
Bit3= Reserved
Bit4= JamWarning
Bit5= UnderloadWarning
Bit6= CurrentImbalWarn
Bit7= L1UnderCurrWarn
Bit8= L2UnderCurrWarn
Bit9= L3UnderCurrWarn
Bit10= L1OverCurrenWarn
Bit11= L2OverCurrenWarn
Bit12= L3OverCurrenWarn
Bit13= L1LineLossWarn
Bit14= L2LineLossWarn
Bit15= L3LineLossWarn
0xFFFF
146 WarnHistoryMaskV C.History.UnderVoltageWarningEn
C.History.OverVoltageWarningEn
C.History.VoltageImbalanceWarningEn
C.History.PhaseRotationMismatchWarningEn
C.History.UnderFrequencyWarningEn
C.History.OverFrequencyWarningEn
Warning History
Mask for Voltage-
based Warnings
UINT 2 1 Bit0= UnderVoltageWarn
Bit1= OvervoltageWarn
Bit2= VoltageUnbalWarn
Bit3= PhaseRotationWrn
Bit4= UnderFreqWarning
Bit5= OverFreqWarning
0x3F
147 WarnHistoryMaskP C.History.UnderRealPowerWarningEn
C.History.OverRealPowerWarningEn
C.History.UnderReactivePowerConsumedWarningEn
C.History.OverReactivePowerConsumedWarningEn
C.History.UnderReactivePowerGeneratedWarningEn
C.History.OverReactivePowerGeneratedWarningEn
C.History.UnderApparentPowerWarningEn
C.History.OverApparentPowerWarningEn
C.History.UnderPowerFactorLaggingWarningEn
C.History.OverPowerFactorLaggingWarningEn
C.History.UnderPowerFactorLeadingWarningEn
C.History.OverPowerFactorLeadingWarningEn
Warning History
Mask for Power-
based Warnings
UINT 2 1 Bit0= UnderKWWarning
Bit1= OverKWWarning
Bit2= UnderKVARConWarn
Bit3= OverKVARConWarn
Bit4= UnderKVARGenWarn
Bit5= OverKVARGenWarn
Bit6= UnderKVAWarning
Bit7= OverKVAWarning
Bit8= UnderPFLagWarn
Bit9= OverPFLagWarn
Bit10= UnderPFLeadWarn
Bit11= OverPFLeadWarn
0xFFF
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
