Rockwell Automation Publication 193-UM015E-EN-P - October 2015 641
Parameter List Appendix B
Trip/Warn History
(continued)
148 WarnHistoryMaskC
C.History.PTCWarningEn
C.History.ModuleMismatchWarningEn
C.History.ExpansionBusWarningEn
C.History.NumberOfStartsWarningEn
C.History.OperatingHoursWarningEn
Warning History
Mask for Control-
based Warnings
UINT 2 1 Bit0= Reserved
Bit1= PTCWarning
Bit2= DLXWarning
Bit3= Reserved
Bit4= Reserved
Bit5= Reserved
Bit6= Reserved
Bit7= ConfigWarning
Bit8= OptionMatchWarn
Bit9= DLXFBTimeoutWarn
Bit10= ExpansionBusWarn
Bit11= PMNumberOfStarts
Bit12= PMOperatingHours
0x1FFF
149 WarnHistoryMaskA C.History.Analog1Ch00WarningEn
C.History.Analog1Ch01WarningEn
C.History.Analog1Ch02WarningEn
C.History.Analog2Ch00WarningEn
C.History.Analog2Ch01WarningEn
C.History.Analog2Ch02WarningEn
C.History.Analog3Ch00WarningEn
C.History.Analog3Ch01WarningEn
C.History.Analog3Ch02WarningEn
C.History.Analog4Ch00WarningEn
C.History.Analog4Ch01WarningEn
C.History.Analog4Ch02WarningEn
Warning History
Mask for Analog
Input Based
Warnings
UINT 2 1 Bit0= InAnMod1Ch00Warn
Bit1= InAnMod1Ch01Warn
Bit2= InAnMod1Ch02Warn
Bit3= InAnMod2Ch00Warn
Bit4= InAnMod2Ch01Warn
Bit5= InAnMod2Ch02Warn
Bit6= InAnMod3Ch00Warn
Bit7= InAnMod3Ch01Warn
Bit8= InAnMod3Ch02Warn
Bit9= InAnMod4Ch00Warn
Bit10=
InAnMod4Ch01Warn
Bit11=
InAnMod4Ch02Warn
0xFFF
150 Reserved
Trip Snapshot
151 TSL1Current Snapshot of the
actual L1 Phase
Current at trip
DINT 4 100 0 2000000000 0 Amps
152 TSL2Current Snapshot of the
actual L2 Phase
Current at trip
DINT 4 100 0 2000000000 0 Amps
153 TSL3Current Snapshot of the
actual L3 Phase
Current at trip
DINT 4 100 0 2000000000 0 Amps
154 TSThermUtilized Snapshot of %
Thermal Capacity
Used at trip
UINT 2 1 0 100 0 %
155 TSGFCurrent Snapshot of the
Ground Fault
Current at trip
INT 2 100 0 2540 0 Amps
156 TSL1toL2Voltage Snapshot of 3
Phase RMS Voltage
Line-Line at trip
UINT 2 10 0 65535 0 Volt
157 TSL2toL3Voltage Snapshot of 3
Phase RMS Voltage
Line-Line at trip
UINT 2 10 0 65535 0 Volt
158 TSL3toL1Voltage Snapshot of 3
Phase RMS Voltage
Line-Line at trip
UINT 2 10 0 65535 0 Volt
159 TSTotalRealPwr Snapshot of Total
Real Power at trip
DINT 4 1000 -
2000000000
2000000000 0 kW
160 TSTotalkVAR Snapshot of Total
Reactive Power at
trip
DINT 4 1000 -
2000000000
2000000000 0 kVAR
161 TSTotalkVA Snapshot of Total
Apparent Power at
trip
DINT 4 1000 0 2000000000 0 kVA
162 TSTotalPF Snapshot of Total
True Power Factor
(PF) at trip
INT 2 10 -1000 1000 0 %
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
