642 Rockwell Automation Publication 193-UM015E-EN-P - November 2013
Appendix B Parameter List
Command 163 TripReset O.TripReset Attempt to reset a
trip
BOOL 0=Ready
1=TripReset
010
164 ConfigPreset IO Configuration
based on Logic
Personality
USINT 0=Ready
1=Factory Defaults
0 54 0
165 ClearCommand Reset
Accumulator(s)
USINT 1 1 0= Ready
1= ClrOperStats
2= ClrHistoryLogs
3= ClrPercentTCU
4= ClrKWh
5= ClrKVARh
6= ClrKVAh
7= ClrMaxKWDemad
8= ClrMaxKVARDemand
9= ClrMaxKVADemand
10= ClearAll
0
166 Reserved
167 Reserved
168 Reserved
169 Reserved
170 Reserved
Overload Setup 171 FLASetting C.FLA1 Overload Full Load
Current Setting
UDINT 4 100 50 6553500 50 Amps
172 TripClass C.TripClass Trip Class Setting USINT 1 1 5 30 10
173 OLPTCResetMode C.OverloadResetMode Overload and PTC
Trip Reset Mode
BOOL 1 1 0=Manual
1=Automatic
0
174 OLResetLevel C.OverloadResetLevel Overload Trip Reset
Level
USINT 1 1 0 100 75 %TCU
175 OLWarningLevel C.OverloadWarningLimit Overload Warning
Reset Level
USINT 1 1 0 100 85 %TCU
176 SingleOrThree Ph C.ThreePhase Single Phase = L1
and L2
BOOL 1 1 0=SinglePhase
1=ThreePhase
1
177 FLA2Setting C.FLA2 Overload Full Load
Current Setting 2
UDINT 4 100 50 6553500 50 Amps
178 Reserved
179 Reserved
180 Reserved
181 Reserved
182 Reserved
Device Setup 183 TripEnableI C.Protection.OverloadTripEnEn
C.Protection.PhaseLossTripEn
C.Protection.GroundFaultCurrentTripEn
C.Protection.StallTripEn
C.Protection.JamTripEn
C.Protection.UnderloadTripEn
C.Protection.CurrentImbalanceTripEn
C.Protection.L1UnderCurrentTripEn
C.Protection.L2UnderCurrentTripEn
C.Protection.L3UnderCurrentTripEn
C.Protection.L1OverCurrentTripEn
C.Protection.L2OverCurrentTripEn
C.Protection.L3OverCurrentTripEn
C.Protection.L1LineLossTripEn
C.Protection.L2LineLossTripEn
C.Protection.L3LineLossTripEn
Bitmask used to
enable/disable
current-based trips
UINT 2 1 Bit0= OverloadTrip
Bit1= PhaseLossTrip
Bit2= GroundFaultTrip
Bit3= StallTrip
Bit4= JamTrip
Bit5= UnderloadTrip
Bit6= CurrentImbalTrip
Bit7= L1UnderCurrTrip
Bit8= L2UnderCurrTrip
Bit9= L3UnderCurrTrip
Bit10= L1OverCurrenTrip
Bit11= L2OverCurrenTrip
Bit12= L3OverCurrenTrip
Bit13= L1LineLossTrip
Bit14= L2LineLossTrip
Bit15= L3LineLossTrip
3
184 TripEnableV C.Protection.UnderVoltageTripEn
C.Protection.OverVoltageTripEn
C.Protection.VoltageImbalanceTripEn
C.Protection.PhaseRotationMismatchTripEn
C.Protection.UnderFrequencyTripEn
C.Protection.OverFrequencyTripEn
Bitmask used to
enable/disable
voltage-based
trips
UINT 2 1 Bit0= UnderVoltageTrip
Bit1= OvervoltageTrip
Bit2= VoltageUnbalTrip
Bit3= PhaseRotationTrp
Bit4= UnderFreqTrip
Bit5= OverFreqTrip
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
To Next Page
