Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 643
Parameter List Appendix B
Device Setup
(continued)
185 TripEnableP C.Protection.UnderRealPowerTripEn
C.Protection.OverRealPowerTripEn
C.Protection.UnderReactivePowerConsumedTripEn
C.Protection.OverReactivePowerConsumedTripEn
C.Protection.UnderReactivePowerGeneratedTripEn
C.Protection.OverReactivePowerGeneratedTripEn
C.Protection.UnderApparentPowerTripEn
C.Protection.OverApparentPowerTripEn
C.Protection.UnderPowerFactorLaggingTripEn
C.Protection.OverPowerFactorLaggingTripEn
C.Protection.UnderPowerFactorLeadingTripEn
C.Protection.OverPowerFactorLeadingTripEn
Bitmask used to
enable/disable
power-based trips
UINT 2 1 Bit0= UnderKWTrip
Bit1= OverKWTrip
Bit2= UnderKVARConTrip
Bit3= OverKVARConTrip
Bit4= UnderKVARGenTrip
Bit5= OverKVARGenTrip
Bit6= UnderKVATrip
Bit7= OverKVATrip
Bit8= UnderPFLagTrip
Bit9= OverPFLagTrip
Bit10= UnderPFLeadTrip
Bit11= OverPFLeadTrip
0
186 TripEnableC C.Protection.TestTripEn
C.Protection.PTCTripEn
C.Protection.OperatorStationTripEn
C.Protection.RemoteTripEn
C.Protection.BlockedStartTripEn
C.Protection.HardwareFaultTripEn
C.Protection.ConfigurationTripEn
C.Protection.ModuleMismatchTripEn
C.Protection.ExpansionBusTripEn
C.Protection.NVMErrorTripEn
C.Protection.MCCTestPositionTripEn
Bitmask used to
enable/disable
control-based trips
UINT 2 1 Bit0= TestTrip
Bit1= PTCTrip
Bit2= DLXTrip
Bit3= OperStationTrip
Bit4= RemoteTrip
Bit5= BlockedStartTrip
Bit6= HardwareFltTrip
Bit7= ConfigTrip
Bit8= OptionMatchTrip
Bit9= DLXFBTimeoutTrip
Bit10= ExpansionBusTrip
Bit11= Reserved
Bit12= Reserved
Bit13= NVSTrip
Bit14=TestModeTrip
1
187 TripEnableA C.Protection.Analog1Ch00TripEn
C.Protection.Analog1Ch01TripEn
C.Protection.Analog1Ch02TripEn
C.Protection.Analog2Ch00TripEn
C.Protection.Analog2Ch01TripEn
C.Protection.Analog2Ch02TripEn
C.Protection.Analog3Ch00TripEn
C.Protection.Analog3Ch01TripEn
C.Protection.Analog3Ch02TripEn
C.Protection.Analog4Ch00TripEn
C.Protection.Analog4Ch01TripEn
C.Protection.Analog4Ch02TripEn
Bitmask used to
enable/disable
analog-based trips
UINT 2 1 Bit0= InAnMod1Ch00Trip
Bit1= InAnMod1Ch01Trip
Bit2= InAnMod1Ch02Trip
Bit3= InAnMod2Ch00Trip
Bit4= InAnMod2Ch01Trip
Bit5= InAnMod2Ch02Trip
Bit6= InAnMod3Ch00Trip
Bit7= InAnMod3Ch01Trip
Bit8= InAnMod3Ch02Trip
Bit9= InAnMod4Ch00Trip
Bit10= InAnMod4Ch01Trip
Bit11= InAnMod4Ch02Trip
0
188 Reserved
189 WarningEnableI C.Protection.OverloadWarningEn
C.Protection.GroundFaultCurrentWarningEn
C.Protection.JamWarningEn
C.Protection.UnderloadWarningEn
C.Protection.CurrentImbalanceWarningEn
C.Protection.L1UnderCurrentWarningEn
C.Protection.L2UnderCurrentWarningEn
C.Protection.L3UnderCurrentWarningEn
C.Protection.L1OverCurrentWarningEn
C.Protection.L2OverCurrentWarningEn
C.Protection.L3OverCurrentWarningEn
C.Protection.L1LineLossWarningEn
C.Protection.L2LineLossWarningEn
C.Protection.L3LineLossWarningEn
Bitmask used to
enable/disable
current-based
warnings
UINT 2 1 Bit0= OverloadWarning
Bit1= Reserved
Bit2= GroundFltWarning
Bit3= Reserved
Bit4= JamWarning
Bit5= UnderloadWarning
Bit6= CurrentImbalWarn
Bit7= L1UnderCurrWarn
Bit8= L2UnderCurrWarn
Bit9= L3UnderCurrWarn
Bit10= L1OverCurrenWarn
Bit11= L2OverCurrenWarn
Bit12= L3OverCurrenWarn
Bit13= L1LineLossWarn
Bit14= L2LineLossWarn
Bit15= L3LineLossWarn
0
190 WarningEnableV C.Protection.UnderVoltageWarningEn
C.Protection.OverVoltageWarningEn
C.Protection.VoltageImbalanceWarningEn
C.Protection.PhaseRotationMismatchWarningEn
C.Protection.UnderFrequencyWarningEn
C.Protection.OverFrequencyWarningEn
Bitmask used to
enable/disable
voltage-based
warnings
UINT 2 1 Bit0= UnderVoltageWarn
Bit1= OvervoltageWarn
Bit2= VoltageUnbalWarn
Bit3= PhaseRotationWrn
Bit4= UnderFreqWarning
Bit5= OverFreqWarning
0
191 WarningEnableP C.Protection.UnderRealPowerWarningEn
C.Protection.OverRealPowerWarningEn
C.Protection.UnderReactivePowerConsumedWarningEn
C.Protection.OverReactivePowerConsumedWarningEn
C.Protection.UnderReactivePowerGeneratedWarningEn
C.Protection.OverReactivePowerGeneratedWarningEn
C.Protection.UnderApparentPowerWarningEn
C.Protection.OverApparentPowerWarningEn
C.Protection.UnderPowerFactorLaggingWarningEn
C.Protection.OverPowerFactorLaggingWarningEn
C.Protection.UnderPowerFactorLeadingWarningEn
C.Protection.OverPowerFactorLeadingWarningEn
Bitmask used to
enable/disable
power-based
warnings
UINT 2 1 Bit0= UnderKWWarning
Bit1= OverKWWarning
Bit2= UnderKVARConWarn
Bit3= OverKVARConWarn
Bit4= UnderKVARGenWarn
Bit5= OverKVARGenWarn
Bit6= UnderKVAWarning
Bit7= OverKVAWarning
Bit8= UnderPFLagWarn
Bit9= OverPFLagWarn
Bit10= UnderPFLeadWarn
Bit11= OverPFLeadWarn
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
