Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 645
Parameter List Appendix B
Device Setup
(continued
199 InPt03Assignment C.Pt03InputFunction_0
C.Pt03InputFunction_1
C.Pt03InputFunction_2
C.Pt03InputFunction_3
Assignment for
Input Point 03
function
USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm
0
200 InPt04Assignment C.Pt03InputFunction_0
C.Pt03InputFunction_1
C.Pt03InputFunction_2
C.Pt03InputFunction_3
Assignment for
Input Point 04
function
USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm
0
201 InPt05Assignment C.Pt05InputFunction_0
C.Pt05InputFunction_1
C.Pt05InputFunction_2
C.Pt05InputFunction_3
Assignment for
Input Point 05
function
USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm
0
202 OutPt0Assignment Assignment for
OutputPt00
function
USINT 1 1 0=Normal
1=TripRelay
2=ControlRelay
3=TripAlarm
4=WarningAlarm
5=MonL1TripRelay
6= MonL2TripRelay
7= MonL3TripRelay
•1 for
firmware
v1.000 and
v2.000
•2 for
firmware
v3.000 and
higher
203 OutPt1Assignment Assignment for
OutputPt01
function
USINT 1 1 0=Normal
1=TripRelay
2=ControlRelay
3=TripAlarm
4=WarningAlarm
5=MonL1TripRelay
6= MonL2TripRelay
7= MonL3TripRelay
0
204 OutPt2Assignment Assignment for
OutputPt02
function
USINT 1 1 0=Normal
1=TripRelay
2=ControlRelay
3=TripAlarm
4=WarningAlarm
5=MonL1TripRelay
6= MonL2TripRelay
7= MonL3TripRelay
0
205 StartsPerHour C.StartsPerHourLimit Allowable Starts
per Hour
USINT 1 1 0 120 2
206 StartsInterval C.StartsIntervalLimit The minimum
allowable interval
between starts
UINT 2 1 0 3600 600
Seconds
207 PMTotalStarts C.TotalStartsLimit Total number of
starts for
preventative
maintenance
UINT 2 1 0 65535 0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
