Allen-Bradley E300 User Manual

650 Rockwell Automation Publication 193-UM015E-EN-P - November 2013
Appendix B Parameter List
Output Setup 304 OutPt00PrFltAct C.Pt00OutputProtectionFaultMode Output Pt00 action
on protection fault
BOOL 1 1 0= GoToPrFltValue
1= IgnoreIfPossible
0
305 OutPt00PrFltVal C.Pt00OutputProtectionFaultValue Output Pt00 value
on protection fault
BOOL 1 1 0=Open
1=Closed
0
306 OutPt00ComFltAct C.Pt00OutputFaultMode Output Pt00 action
on comms fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
307 OutPt00ComFltVal C.Pt00OutputFaultValue Out Pt00 value on
comms fault
BOOL 1 1 0=Open
1=Closed
0
308 OutPt00ComIdlAct C.Pt00OutputProgMode Output Pt00 action
on comms idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
309 OutPt00ComIdlVal C.Pt00OutputProgValue Output Pt00 value
on comms idle
BOOL 1 1 0=Open
1=Closed
0
310 OutPt01PrFltAct C.Pt01OutputProtectionFaultMode Output Pt01 action
on protection fault
BOOL 1 1 0= GoToPrFltValue
1= IgnoreIfPossible
0
311 OutPt01PrFltVal C.Pt01OutputProtectionFaultValue Output Pt01 value
on protection fault
BOOL 1 1 0=Open
1=Closed
0
312 OutPt01ComFltAct C.Pt01OutputFaultMode Output Pt01 action
on comms fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
313 OutPt01ComFltVal C.Pt01OutputFaultValue Output Pt01 value
on comms fault
BOOL 1 1 0=Open
1=Closed
0
314 OutPt01ComIdlAct C.Pt01OutputProgMode Output Pt01 action
on comms idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
315 OutPt01ComIdlVal C.Pt01OutputProgValue Output Pt01 value
on comms idle
BOOL 1 1 0=Open
1=Closed
0
316 OutPt02PrFltAct C.Pt02OutputProtectionFaultMode Output Pt02 action
on protection fault
BOOL 1 1 0= GoToPrFltValue
1= IgnoreIfPossible
0
317 OutPt02PrFltVal C.Pt02OutputProtectionFaultValue Output Pt02 value
on protection fault
BOOL 1 1 0=Open
1=Closed
0
318 OutPt02ComFltAct C.Pt02OutputFaultMode Output Pt02 action
on comms fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
319 OutPt02ComFltVal C.Pt02OutputFaultValue Output Pt02 value
on comms fault
BOOL 1 1 0=Open
1=Closed
0
320 OutPt02ComIdlAct C.Pt02OutputProgMode Output Pt02 action
on comms idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
321 OutPt02ComIdlVal C.Pt02OutputProgValue Output Pt02 value
on comms idle
BOOL 1 1 0=Open
1=Closed
0
322 OutDig1PrFltAct C.Digital1ProtectionFaultMode Digital Expansion
Module 1 Outputs
action on
protection fault
BOOL 1 1 0= GoToPrFltValue
1= Ignore
0
323 OutDig1PrFltVal C.Digital1ProtectionFaultValue Digital Expansion
Module 1 Outputs
value on
protection fault
BOOL 1 1 0=Open
1=Closed
0
324 OutDig1ComFltAct C.Digital1FaultMode Digital Expansion
Module 1 Outputs
action on comms
fault
BOOL 1 1 0= GoToCommFltValue
1= HoldLastState
0
325 OutDig1ComFltVal C.Digital1FaultValue Digital Expansion
Module 1 Outputs
value on comms
fault
BOOL 1 1 0=Open
1=Closed
0
326 OutDig1ComIdlAct C.Digital1ProgMode Digital Expansion
Module 1 Outputs
action on comms
idle
BOOL 1 1 0= GoToCommIdlValue
1= HoldLastState
0
327 OutDig1ComIdlVal C.Digital1ProgValue Digital Expansion
Module 1 Outputs
value on comms
idle
BOOL 1 1 0=Open
1=Closed
0
328 OutDig2PrFltAct C.Digital2ProtectionFaultMode Digital Expansion
Module 2 Outputs
action on
protection fault
BOOL 1 1 0= GoToPrFltValue
1= Ignore
0
329 OutDig2PrFltVal C.Digital2ProtectionFaultValue Digital Expansion
Module 2 Outputs
value on
protection fault
BOOL 1 1 0=Open
1=Closed
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
