Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 649
Parameter List Appendix B
Current Setup
continued
277 L1OCTripLevel C.L1OverCurrentTripLimit L1 Over Current
Trip Level
USINT 1 1 10 200 100 %
278 L1OCWarningLevel C.L1OverCurrentWarnLimit L1 Over Current
Warning Level
USINT 1 1 10 200 90 %
279 L2OCTripDelay L2 Over Current
Trip Delay
USINT 1 10 0 250 10
Seconds
280 L2OCTripLevel C.L2OverCurrentTripDelay L2 Over Current
Trip Level
USINT 1 1 10 200 100 %
281 L2OCWarningLevel C.L2OverCurrentTripLimit L2 Over Current
Warning Level
USINT 1 1 10 200 90 %
282 L3OCTripDelay C.L2OverCurrentWarnLimit L3 Over Current
Trip Delay
USINT 1 10 0 250 10
Seconds
283 L3OCTripLevel C.L3OverCurrentTripDelay L3 Over Current
Trip Level
USINT 1 1 10 200 100 %
284 L3OCWarningLevel C.L3OverCurrentTripLimit L3 Over Current
Warning Level
USINT 1 1 10 200 90 %
285 LineLossInhTime C.L3OverCurrentWarnLimit Line Loss Inhibit
Time
USINT 1 1 0 250 10
Seconds
286 L1LossTripDelay C.LineLossInhibitTime L1 Line Loss Trip
Delay
USINT 1 10 0 250 10
Seconds
287 L2LossTripDelay C.L1LineLossTripDelay L2 Line Loss Trip
Delay
USINT 1 10 0 250 10
Seconds
288 L3LossTripDelay C.L2LineLossTripDelay L3 Line Loss Trip
Delay
USINT 1 10 0 250 10
Seconds
Communication
Setup
289 OutputAssembly C.L3LineLossTripDelay Output Assembly
Instance used by IO
Connections
UINT 2 1 0 180 144
290 InputAssembly Input Assembly
Instance used by IO
Connections
UINT 2 1 0 300 300
291 Datalink0 Produced I/O
Assembly
Datalink0
Parameter Number
UINT 2 1 0 560 0
292 Datalink1 Produced I/O
Assembly
Datalink1
Parameter Number
UINT 2 1 0 560 0
293 Datalink2 Produced I/O
Assembly
Datalink2
Parameter Number
UINT 2 1 0 560 0
294 Datalink3 Produced I/O
Assembly
Datalink3
Parameter Number
UINT 2 1 0 560 0
295 Datalink4 Produced I/O
Assembly
Datalink4
Parameter Number
UINT 2 1 0 560 0
296 Datalink5 Produced I/O
Assembly
Datalink5
Parameter Number
UINT 2 1 0 560 0
297 Datalink6 Produced I/O
Assembly
Datalink6
Parameter Number
UINT 2 1 0 560 0
298 Datalink7 Produced I/O
Assembly
Datalink7
Parameter Number
UINT 2 1 0 560 0
299 Reserved
300 Reserved
301 Reserved
302 Reserved
303 Reserved
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
