Allen-Bradley E300 User Manual

648 Rockwell Automation Publication 193-UM015E-EN-P - November 2013
Appendix B Parameter List
Current Setup
continued
246 GFWarningLevel C.GroundFaultWarnLimit Ground Fault
Warning Level
UINT 2 100 2 500 200 Amps
247 GFFilter C.GroundFaultFilterEn Filter GF current
from %TCU
calculation
BOOL 1 1 0=Disable
1=Enable
0
248 GFMaxInhibit C.GroundFaultMaxInhibitEn Trip is inhibited
when GF exceeds
max value
BOOL 1 1 0=Disable
1=Enable
0
249 StallEnabledTime C.StallEnabledTime Stall Monitor and
Trip Delay
USINT 1 1 0 250 10
Seconds
250 StallTripLevel C.StallTripLimit Stall Trip Level UINT 2 10 100 600 600 %FLA
251 JamInhibitTime C.JamInhibitTime Jam Detect Inhibit
Time
USINT 1 1 0 250 10
Seconds
252 JamTripDelay C.JamTripDelay Jam Detect Trip
Delay
USINT 1 10 1 250 50
Seconds
253 JamTripLevel C.JamTripLimit Jam Detect Trip
Level
UINT 2 1 50 600 250 %FLA
254 JamWarningLevel C.JamWarnLimit Jam Detect
Warning Level
UINT 2 1 50 600 150 %FLA
255 ULInhibitTime C.UnderloadInhibitTime Underload Inhibit
Time
USINT 1 1 0 250 10
Seconds
256 ULTripDelay C.UnderloadTripDelay Underload Trip
Delay
USINT 1 10 1 250 50
Seconds
257 ULTripLevel C.UnderloadTripLimit Underload Trip
Level
USINT 1 1 10 100 50 %FLA
258 ULWarningLevel C.UnderloadWarnLimit Underload
Warning Level
USINT 1 1 10 100 70 %FLA
259 CIInhibitTime C.CurrentImbalanceInhibitTime Current Imbalance
Inhibit Time
USINT 1 1 0 250 10
Seconds
260 CITripDelay C.CurrentImbalanceTripDelay Current Imbalance
Trip Delay
USINT 1 10 1 250 50
Seconds
261 CITripLevel C.CurrentImbalanceTripLimit Current Imbalance
Trip Level
USINT 1 1 10 100 35 %
262 CIWarningLevel C.CurrentImbalanceWarnLimit Current Imbalance
Warning Level
USINT 1 1 10 100 20 %
263 CTPrimary C.CTPrimary Current
Tra nsf orm er
Primary Ratio
UINT 2 1 1 65535 5
264 CTSecondary C.CTSecondary Current
Tra nsf orm er
Secondary Ratio
UINT 2 1 1 65535 5
265 UCInhibit Time C.UnderCurrentInhibitTime Under Current
Inhibit Time
USINT 1 1 0 250 10
Seconds
266 L1UCTripDelay C.L1UnderCurrentTripDelay L1 Under Current
Trip Delay
USINT 1 10 0 250 10
Seconds
267 L1UCTripLevel C.L1UnderCurrentTripLimit L1 Under Current
Trip Level
USINT 1 1 10 100 35 %
268 L1UCWarningLevel C.L1UnderCurrentWarnLimit L1 Under Current
Warning Level
USINT 1 1 10 100 40 %
269 L2UCTripDelay C.L2UnderCurrentTripDelay L2 Under Current
Trip Delay
USINT 1 10 0 250 10
Seconds
270 L2UCTripLevel C.L2UnderCurrentTripLimit L2 Under Current
Trip Level
USINT 1 1 10 100 35 %
271 L2UCWarningLevel C.L2UnderCurrentWarnLimit L2 Under Current
Warning Level
USINT 1 1 10 100 40 %
272 L3UCTripDelay C.L3UnderCurrentTripDelay L3 Under Current
Trip Delay
USINT 1 10 0 250 10
Seconds
273 L3UCTripLevel C.L3UnderCurrentTripLimit L3 Under Current
Trip Level
USINT 1 1 10 100 35 %
274 L3UCWarningLevel C.L3UnderCurrentWarnLimit L3 Under Current
Warning Level
USINT 1 1 10 100 40 %
275 OCInhibitTime C.OverCurrentInhibitTime Over Current
Inhibit Time
USINT 1 1 0 250 10
Seconds
276 L1OCTripDelay C.L1OverCurrentTripDelay L1 Over Current
Trip Delay
USINT 1 10 0 250 10
Seconds
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
