Allen-Bradley E300 User Manual

654 Rockwell Automation Publication 193-UM015E-EN-P - November 2013
Appendix B Parameter List
Power Setup
(Continued)
392 OVARCTripLevel C.OverReactivePowerConsumedTripLimit Over Total Reactive
Power Consumed
(+kVAR) Trip Level
DINT 4 1000 0 2000000000 0 kVAR
393 OVARCWarnLevel C.OverReactivePowerConsumedWarnLimit Over Total Reactive
Power Consumed
(+kVAR) Warning
Level
DINT 4 1000 0 2000000000 0 kVAR
394 UVARGInhibitTime C.UnderReactivePowerGeneratedInhibitTime Under Total
Reactive Power
Generated (-kVAR)
Inhibit Time
USINT 1 1 0 250 10
Seconds
395 UVARGTripDelay C.UnderReactivePowerGeneratedTripDelay Under Total
Reactive Power
Generated (-kVAR)
Trip Delay
USINT 1 10 1 250 10
Seconds
396 UVARGTripLevel C.UnderReactivePowerGeneratedTripLimit Under Total
Reactive Power
Generated (-kVAR)
Trip Level
DINT 4 1000 -
2000000000
0 0 kVAR
397 UVARGWarnLevel C.UnderReactivePowerGeneratedWarnLimit Under Total
Reactive Power
Generated (-kVAR)
Warning Level
DINT 4 1000 -
2000000000
00kVAR
398 OVARGInhibitTime C.OverReactivePowerGeneratedInhibitTime Over Total Reactive
Power Generated
(-kVAR) Inhibit
Time
USINT 1 1 0 250 10
Seconds
399 OVARGTripDelay C.OverReactivePowerGeneratedTripDelay Over Total Reactive
Power Generated
(-kVAR) Trip Delay
USINT 1 10 1 250 10
Seconds
400 OVARGTripLevel C.OverReactivePowerGeneratedTripLimit Over Total Reactive
Power Generated
(-kVAR) Trip Level
DINT 4 1000 -
2000000000
0 0 kVAR
401 OVARGWarnLevel C.OverReactivePowerGeneratedWarnLimit Over Total Reactive
Power Generated
(-kVAR) Warning
Level
DINT 4 1000 -
2000000000
00kVAR
402 UVAInhibitTime C.UnderApparentPowerInhibitTime Under Total
Apparent Power
Inhibit Time
USINT 1 1 0 250 10
Seconds
403 UVATripDelay C.UnderApparentPowerTripDelay Under Total
Apparent Power
Trip Delay
USINT 1 10 1 250 10
Seconds
404 UVATripLevel C.UnderApparentPowerTripLimit Under Total
Apparent Power
Trip Level
DINT 4 1000 0 2000000000 0 kVA
405 UVAWarningLevel C.UnderApparentPowerWarnLimit Under Total
Apparent Power
Warning Level
DINT 4 1000 0 2000000000 0 kVA
406 OVAInhibitTime C.OverApparentPowerInhibitTime Over Total
Apparent Power
Inhibit Time
USINT 1 1 0 250 10
Seconds
407 OVATripDelay Over Total
Apparent Power
Trip Delay
USINT 1 10 1 250 10
Seconds
408 OVATripLevel C.OverApparentPowerTripDelay Over Total
Apparent Power
Trip Level
DINT 4 1000 0 2000000000 0 kVA
409 OVAWarningLevel C.OverApparentPowerWarnLimit Over Total
Apparent Power
Warning Level
DINT 4 1000 0 2000000000 0 kVA
410 UPFLagInhibTime C.UnderPowerFactorLaggingInhibitTime Under Total Power
Factor Lagging (-
PF) Inhibit Time
USINT 1 1 0 250 10
Seconds
411 UPFLagTripDelay C.UnderPowerFactorLaggingTripDelay Under Total Power
Factor Lagging (-
PF) Trip Delay
USINT 1 10 1 250 10
Seconds
412 UPFLagTripLevel C.UnderPowerFactorLaggingTripLimit Under Total Power
Factor Lagging (-
PF) Trip Level
SINT 1 1 -100 0 -90 %
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
