Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 653
Parameter List Appendix B
Voltage Setup
(continued)
366 VIBTripDelay C.VoltageImbalanceTripDelay Voltage Imbalance
Trip Delay
USINT 1 10 1 250 10
Seconds
367 VIBTripLevel C.VoltageImbalanceTripLimit Voltage Imbalance
Trip Level
USINT 1 1 0 100 85 %
368 VIBWarningLevel C.VoltageImbalanceWarnLimit Voltage Imbalance
Warning Level
USINT 1 1 0 100 75 %
369 UFInhibitTime C.UnderFrequencyInhibitTime Under Frequency
Inhibit Time
USINT 1 1 0 250 10
Seconds
370 UFTripDelay C.UnderFrequencyTripDelay Under Frequency
Trip Delay
USINT 1 10 1 250 10
Seconds
371 UFTripLevel C.UnderFrequencyTripLimit Under Frequency
Trip Level
USINT 1 1 46 65 57 Hz
372 UFWarningLevel C.UnderFrequencyWarnLimit Under Frequency
Warning Level
USINT 1 1 46 65 58 Hz
373 OFInhibitTime C.OverFrequencyInhibitTime Over Frequency
Inhibit Time
USINT 1 1 0 250 10
Seconds
374 OFTripDelay C.OverFrequencyTripDelay Over Frequency
Trip Delay
USINT 1 10 1 250 10
Seconds
375 OFTripLevel C.OverFrequencyTripLimit Over Frequency
Trip Level
USINT 1 1 46 65 63 Hz
376 OFWarningLevel C.OverFrequencyWarnLimit Over Frequency
Warning Level
USINT 1 1 46 65 62 Hz
Power Setup 377 PowerScale C.PowerScale Power value scale
factor (kW MW)
USINT 1 1 0=kW
1=MW
0
378 UWInhibitTime C.UnderRealPowerInhibitTime Under Total Real
Power Inhibit Time
USINT 1 1 0 250 10
Seconds
379 UWTripDelay C.UnderRealPowerTripDelay Under Total Real
Power Trip Delay
USINT 1 10 1 250 10
Seconds
380 UWTripLevel C.UnderRealPowerTripLimit Under Total Real
Power Trip Level
DINT 4 1000 0 2000000000 0 kW
381 UWWarningLevel C.UnderRealPowerWarnLimit Under Total Real
Power Warning
Level
DINT 4 1000 0 2000000000 0 kW
382 OWInhibitTime C.OverRealPowerInhibitTime Over Total Real
Power Inhibit Time
USINT 1 1 0 250 10
Seconds
383 OWTripDelay C.OverRealPowerTripDelay Over Total Real
Power Trip Delay
USINT 1 10 1 250 10
Seconds
384 OWTripLevel C.OverRealPowerTripLimit Over Total Real
Power Trip Level
DINT 4 1000 0 2000000000 0 kW
385 OWWarningLevel C.OverRealPowerWarnLimit Over Total Real
Power Warning
Level
DINT 4 1000 0 2000000000 0 kW
386 UVARCInhibitTime C.UnderReactivePowerConsumedInhibitTime Under Total
Reactive Power
Consumed
(+kVAR) Inhibit
Time
USINT 1 1 0 250 10
Seconds
387 UVARCTripDelay C.UnderReactivePowerConsumedTripDelay Under Total
Reactive Power
Consumed
(+kVAR) Trip Delay
USINT 1 10 1 250 10
Seconds
388 UVARCTripLevel C.UnderReactivePowerConsumedTripLimit Under Total
Reactive Power
Consumed
(+kVAR) Trip Level
DINT 4 1000 0 2000000000 0 kVAR
389 UVARCWarnLevel C.UnderReactivePowerConsumedWarnLimit Under Total
Reactive Power
Consumed
(+kVAR) Warning
Level
DINT 4 1000 0 2000000000 0 kVAR
390 OVARCInhibitTime C.OverReactivePowerConsumedInhibitTime Over Total Reactive
Power Consumed
(+kVAR) Inhibit
Time
USINT 1 1 0 250 10
Seconds
391 OVARCTripDelay C.OverReactivePowerConsumedTripDelay Over Total Reactive
Power Consumed
(+kVAR) Trip Delay
USINT 1 10 1 250 10
Seconds
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
