Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 689
EtherNet/IP Information Appendix D
54
27
CIInhibitTime 8 259
CITripDelay 8260
55
CITripLevel 8 261
CIWarningLevel 8262
56
28
CTPrimary 16 263
57 CTSecondary 16 264
58
29
UCInhibitTime 8 265
L1UCTripDelay 8266
59
L1UCTripLevel 8 267
L1UCWarningLevel 8 268
60
30
L2UCTripDelay 8 269
L2UCTripLevel 8270
61
L2UCWarningLevel 8 271
L3UCTripDelay 8272
62
31
L3UCTripLevel 8 273
L3UCWarningLevel 8 274
63
OCInhibitTime 8 275
L1OCTripDelay 8276
64
32
L1OCTripLevel 8 277
L1OCWarningLevel 8 278
65
L2OCTripDelay 8 279
L2OCTripLevel 8280
66
33
L2OCWarningLevel 8 281
L3OCTripDelay 8282
67
L3OCTripLevel 8 283
L3OCWarningLevel 8 284
68
34
LineLossInhTime 8 285
L1LossTripDelay 8286
69
L2LossTripDelay 8 287
L3LossTripDelay 8288
70
35
Datalink0 16 291
71 Datalink1 16 292
72
36
Datalink2 16 293
73 Datalink3 16 294
74
37
Datalink4 16 295
75 Datalink5 16 296
76
38
Datalink6 16 297
77 Datalink7 16 298
INTDINT1514131211109876543210Size (bits)Param

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
