Allen-Bradley E300 User Manual

690 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Appendix D EtherNet/IP Information
78
39
OutPt00PrFltAct X 1 304
OutPt00PrFltVal X 1 305
OutPt00ComFltAct X 1 306
OutPt00ComFltVal X 1 307
OutPt00ComIdlAct X 1 308
OutPt00ComIdlVal X 1 309
OutPt01PrFltAct X 1 310
OutPt01PrFltVal X 1 311
X OutPt01ComFltAct 1 312
X OutPt01ComFltVal 1 313
X OutPt01ComIdlAct 1 314
X OutPt01ComIdlVal 1 315
X OutPt02PrFltAct 1 316
X OutPt02PrFltVal 1 317
X OutPt02ComFltAct 1 318
X OutPt02ComFltVal 1 319
79
OutPt02ComIdlAct X 1 320
OutPt02ComIdlVal X 1 321
OutDig1PrFltAct X 1 322
OutDig1PrFltVal X 1 323
OutDig1ComFltAct X 1 324
OutDig1ComFltVal X 1 325
OutDig1ComIdlAct X 1 326
OutDig1ComIdlVal X 1 327
XOutDig2PrFltAct 1 328
XOutDig2PrFltVal 1329
X OutDig2ComFltAct 1 330
X OutDig2ComFltVal 1 331
X OutDig2ComIdlAct 1 332
X OutDig2ComIdlVal 1 333
XOutDig3PrFltAct1334
XOutDig3PrFltVal1335
80
40
OutDig3ComFltAct X 1 336
OutDig3ComFltVal X 1 337
OutDig3ComIdlAct X 1 338
OutDig3ComIdlVal X 1 339
OutDig4PrFltAct X 1 340
OutDig4PrFltVal X 1 341
OutDig4ComFltAct X 1 342
OutDig4ComFltVal X 1 343
X OutDig4ComIdlAct 1 344
X OutDig4ComIdlVal 1 345
X CommOverride 1 346
X NetworkOverride 1 347
Reserved 4N/A
81 PtDevOutCOSMask 16 350
82
41
PTPrimary 16 353
83 PTSecondary 16 354
INTDINT1514131211109876543210Size (bits)Param

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
