Table 59 - Output Relay 0 Protection Fault Value (Parameter 305)
Output Relay 1 Protection Fault Action (Parameter 310)
Output Relay 1 Protection Fault Action (Parameter 310) defines how Output
Relay 1 responds when a trip event occurs when this parameter is assigned as a
Normal/General Purpose Relay.
Table 60 - Output Relay 1 Protection Fault Action (Parameter 310)
Output Relay 1 Protection Fault Value (Parameter 311)
Output Relay 1 Protection Fault Value (Parameter 311) defines which state
Output Relay 1 should go to when a trip event occurs.
Table 61 - Output Relay 1 Protection Fault Value (Parameter 311)
Output Relay 2 Protection Fault Action (Parameter 316)
Output Relay 2 Protection Fault Action (Parameter 316) defines how Output
Relay 2 responds when a trip event occurs when this parameter is assigned as a
Normal/General Purpose Relay.
Table 62 - Output Relay 2 Protection Fault Action (Parameter 316)
Output Relay 2 Protection Fault Value (Parameter 317)
Output Relay 2 Protection Fault Value (Parameter 317) defines which state
Output Relay 2 should go to when a trip event occurs.
Table 63 - Output Relay 2 Protection Fault Value (Parameter 317)
Value Assignment Description
0Open Open Output Relay 0
1 Closed Close Output Relay 0
Value Assignment Description
0 GoToPrFltValue Set to Output Relay 1 Protection Fault Value (Parameter 311)
1 IgnoreIfPossible Continue to operate as commanded via the network or DeviceLogix
Value Assignment Description
0Open Open Output Relay 1
1 Closed Close Output Relay 1
Value Assignment Description
0 GoToPrFltValue Set to Output Relay 2 Protection Fault Value (Parameter 317)
1 IgnoreIfPossible Continue to operate as commanded via the network or DeviceLogix
Value Assignment Description
0Open Open Output Relay 2
1 Closed Close Output Relay 2
