Rockwell Automation Publication 193-UM015E-EN-P - October 2015 99
System Operation and Configuration Chapter 4
Digital Expansion Module 1 Output Relay Protection Fault Action (Parameter 322)
Digital Expansion Module 1 Output Relay Protection Fault Action (Parameter
322) defines how both output relays on Digital Expansion Module 1 responds
when a trip event occurs.
Table 64 - Digital Expansion Module 1 Output Relay Protection Fault Action (Parameter 322)
Digital Expansion Module 1 Output Relay Protection Fault Value (Parameter 323)
Digital Expansion Module 1 Output Relay Protection Fault Value
(Parameter 323) defines which state both output relays should go to when a trip
event occurs.
Table 65 - Digital Expansion Module 1 Output Relay Protection Fault Value (Parameter 323)
Digital Expansion Module 2 Output Relay Protection Fault Action (Parameter 328)
Digital Expansion Module 2 Output Relay Protection Fault Action (Parameter
328) defines how both output relays on Digital Expansion Module 2 responds
when a trip event occurs.
Table 66 - Digital Expansion Module 2 Output Relay Protection Fault Action (Parameter 328)
Digital Expansion Module 2 Output Relay Protection Fault Value (Parameter 329)
Digital Expansion Module 2 Output Relay Protection Fault Value (Parameter
329) defines which state both output relays should go to when a trip event occurs.
Table 67 - Digital Expansion Module 2 Protection Fault Value (Parameter 329)
Digital Expansion Module 3 Output Relay Protection Fault Action (Parameter 334)
Digital Expansion Module 3 Output Relay Protection Fault Action (Parameter
334) defines how both output relays on Digital Expansion Module 3 responds
when a trip event occurs.
Value Assignment Description
0GoToPrFltValue
Set to Digital Expansion Module 1 Output Relay Protection Fault Value
(Parameter 323)
1 IgnoreIfPossible Continue to operate as commanded via the network or DeviceLogix
Value Assignment Description
0 Open Open Digital Expansion Module 1 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 1 Output Relay 0 and Output Relay 1
Value Assignment Description
0GoToPrFltValue
Set to Digital Expansion Module 2 Output Relay Protection Fault Value
(Parameter 329)
1 IgnoreIfPossible Continue to operate as commanded via the network or DeviceLogix
Value Assignment Description
0
Open Open Digital Expansion Module 2 Output Relay 0 and Output Relay 1
1 Closed Close Digital Expansion Module 2 Output Relay 0 and Output Relay 1
