Barco HDF W series Service Manual

6. Removal and installation of the projector covers
6.2 Removal of the side cover
CAUTION: Remove the side cover of the projector only in a clean and dust free area. Never remove the side
cover in an area which is subject to airborne contaminants such as that produced by smoke machines or
similar.
Necessary tools
7mmflat screw drive r.
How to remove the side cover
1. R elease the captive s crew at the m iddle bottom of the side cover, us ing a flat screw d river.
Image 6-3
Captive screw
2. R emov e the side cover from the projector as follows:
a) gently pull out the bottom corners (A) of the side cover,
b) then gently pull out the top corners (B) of the side cover,
c) then move the side c over away from the projector (C).
Image 6-4
Cover removal
R5905312 HDF W SERIES 24/01/2013 99
