Barco HDF W series Service Manual

8. Lamp and lamp house
8.3 Installation of the lamp house
WARNING: This procedure may only be performed by qualified technical service personnel.
CAUTION: Never attempt to disassemble the lamp from its housing or to dispose of it. Return it to Barco.
Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled.
Necessary tools
7mmflat screw drive r.
How to install the lamp house of the projector ?
1. E nsure the projector is switched off and the power c ord at the projector side is unplugge d.
2. R emov e the lamp cover, if not removed yet. See "Removal of the lamp cover", page 100.
3. C lasp the lam p house by its handles and gently slide the lamp house into its socket. N ote that the com partment is provided with
guides (G) to position the lam p hous e c orrectly.
C
G
Image 8-5
Insert lamp house
4. P ush the lamp house forward until it slides fully into the projector.
5. S ecure the c orrect position of the lamp house by tightening all three spring lock screws as illustrated.
R5905312 HDF W SERIES 24/01/2013
121
