8. LAMP AND LAMP HOUSE
About this chapter
This chapter the Lamp House and how to replace the xenon lamp in the Lamp H ouse. Also included a re the procedure to reset the
lamp param eters, whic h is required after a x enon lamp re placemen t, and the pr ocedure to realign the lamp in its reflector for optimal
performance.
WARNING: DO NOT PERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF
XENON LAMP HANDLING OR SERVICE. ONLY TRAINED AND QUALIFIED TECHNICAL SERVICE PERSONNEL
ARE ALLOWED TO HANDLE THE XENON LAMP.
CAUTION: Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature
of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance
to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or
otherwise mishandled. Whenever the lamp house, containing a xenon lamp, has to be dismantled or whenever
the protective container or cloth has to be removed from the xenon lamp, authorized protective clothing MUST
be worn!
WARNING: Always wear face protection (full face shield) when handling xenon lamps.
WARNING: Always wear protective clothing (welder’s jacket) when handling xenon lamps.
WARNING: Always wear clean leather gloves with wrist prote
ctors when handling xenon lamps.
Overview
• Introduction HDF Lamp & Lam p House
• Removal of the lamp house
• Installation of the lamp house
• Removing the x enon lam p from the lamp house
• Installing the xenon lamp in the lamp h ouse
• Resetting the lamp parameters
• Realignment of the lamp in its reflector
• Cleaning the U V blocker of the L amp House
• Cleaning the Reflector of the Lamp Hous e
• Lamp info module replacement
R5905312 HDF W SERIES 24/01/2013
117
To Next Page
