8. Lamp and lamp house
8.5 Installing the xenon lamp in the lamp house
WARNING: DO NOT PERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF
XENON LAMP HANDLING OR SERVICE. ONLY TRAINED AND QUALIFIED TECHNICAL SERVICE PERSONNEL
ARE ALLOWED TO HANDLE THE XENON LAMP.
WARNING: This procedure may only be performed by qualified technical service personnel.
CAUTION: Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature
of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance
to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or
otherwise mishandled. Whenever the lamp house, containing a xenon lamp, has to be dismantled or whenever
the protective container or cloth has to be removed from the xenon lamp, authorized protective clothing MUST
be worn!
WARNING: Always wear face protection (full face shield) when handling xenon lamps.
WARNING: Always wear protective clothing (welder’s jacket) when handling xenon lamps.
WARNING: Always wear clean leather gloves with wrist protectors when handling xenon lamps.
Necessary tools
• Welder’s jacket (not included in the safety kit that B arco offers).
• Full face shield with nec k protection.
• Leather gloves with wrist protection.
• Flat scre w driver.
• 17 m m open-end wrench.
• Torque wrench.
• 17 m m hexagon socket.
• Torque screwdriver.
• 2 mm Allen sock et.
• 5 mm Allen sock et.
• 2,5 mm Allen wrench.
• 7 mm nut driver.
How to install the xenon lamp
1. R emov e the U V blocker and side cover of the lamp house by releasing the retaining t humbscrews as illustrated.
Note: In case of a lam p replacement, the UV blocker will be al
ready removed.
