14. Lenses and Lens Holder
14. LENSES AND LENS HOLDER
CAUTION: Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens
before transporting the projector. Neglecting this can damage the Lens Holder and Prism.
Overview
• Introduction Lens Holder
• Available lenses
• Lens selection
• Lens installation
• Lens rem oval
• Lens safety cable
• Cleaning the lens
• Removing the Lens Holder
• Mounting a new Lens Ho lder
• Scheimpflug adjustment
• Replacement of the Vertical Shift stepper motor
• Replacement of the Horizontal Shift stepper motor
R5905312 HDF W SERIES 24/01/2013
