15. Liquid cooling circuit
15.2 Filling the liquid cooling circuit
This procedure can only be used to fill an empty (drained) cooling circuit.
Necessary tools
• Half a m eter of plastic tube with male v alved fitting.
• Half a meter of plas tic tube with female valved fitting.
• Syringe connected with short tube with male valve d fitting.
• Bottle with c ooling liquid.
• Empty bottle with a volum e of 1 liter.
•Cloths.
How to fill the liquid cooling circuit ?
1. Interrupt the liquid cooling circuit by uncoupling the valved fitting at t he heat exchanger.
1
2
Image 15-7
Uncouple heat exchanger
2. C ouple a plastic tube, which conta
ins a female v alved fitting, to the e xit side of the c ooling c ircuit and lead the tube end to an
empty bottle.
244
R5905312 HDF W SERIES 24/01/2013
