14. Lenses and Lens Holder

14.9 Mounting a new Lens Holder

Necessary tools

•7mmﬂat scre w d river.

• Side cutter.

• 3 m m Allen wrench.

• 5 m m Allen wrench.

How to mount

1. P lace the Lens Holder on the projector c hassis and fasten with the 4 screws (reference 5 image 14-34). Usea5mmAllen

wrench.

Note: One motor must point the right side of the projector and the other one m ust point to the top of the pr ojector.

5 5

Image 14-34

R5905312 HDF W SERIES 24/01/2013 229

Default Chapter5
