Barco HDF W series Service Manual

10. Card Cage
10.15 Replacing the Local Keypad backlight
Necessary tools
PH1 Phillips s crewdr iver
How to replace the backlight of the Local Keypad?
1. S witch off the pr ojector, disconnect the power to the projector m ains term inals and unplug the power cord at UPS INLET for
removal of all power from the projector.
2. R emov e the input cover.
3. R emov e the 5 screws (reference 1 image 10-36), unplug the electrical c onnector (reference 2 image 10-36) and remove the
backlight.
4. B ring the new backlight into position, install the 5 screws (reference 1 im age 10-36) and plug in the electrical connector (reference
2 image 10- 36).
1
1
1
1
1
2
Image 10-36
R5905312 HDF W SERIES 24/01/2013 165
