Barco HDF W series Service Manual

2. General
2.1 Convention projector orientation
Convention
This manual refers to the left side of the projector as the side at your left hand when standing behind the projector and looking at
the projection screen in front of the p rojector.
1
5
4
3
2
Image 2-1
1
Front side (lens side)
2
Right side projector (lamp & input side)
3Backside
4 Top side
5
Left side (light process or side)
10
R5905312 HDF W SERIES 24/01/2013
