Barco HDF W series Service Manual

15. Liquid cooling circuit
Image 15-29
Rotor
4. C lean the pump house, the rotor and the pump motor with a clean soft cloth. U se cotton swabs to clean the bearing inside the
pump motor and pump house.
Caution: The bearings of the Pump are fragile. Be careful when cleaning.
5. R einsert the ro tor and try to turn it smoothly. If not successful stop this procedure and replace the pump completely.
6. S lide the p ump hous e w ith hose back on the pump m otor.
Caution: Make sure the sea ling ring of the Pump motor is no t damaged and is on its place.
7. Fas ten the four screws (reference 1) o f the pump house crosswise.
1
1
1
1
Image 15-30
Pump house, close
Refill the liquid cooling circuit in case the pump is successfully cleaned. If cleaning is not possible, replace
the pump completely.
258 R5905312 HDF W SERIES 24/01/2013
