16. Heat exchanger

6. S ecure with a clip (4). Push both clip tongs together and slide the clip on the hose. Release the tongs and it clamps automatically.

Take care not to bend the soft copper tubes of the heat exchanger while sliding the hoses onto

274 R5905312 HDF W SERIES 24/01/2013
