Barco HDF W series Service Manual

19. Board Diagnostic LED’s
Ref. Description (LED
color)
Comment
6
SDI DCM LOCKED
(green)
This LED lit up in norm al condition and indicates that the internal clock (inside FPGA) for the S DI
is locked.
7
HOT PLUG DET ECT
(green)
This LED lit up in case a D V I cable is connected with the DVI input.
8
SEL DVI (green)
This LED it up when the D V I input is selected.
9
SYNC DVI (y ellow) This LED lit up when a valid input sync is detected for the applied D VI source.
10
SEL SDI 1 (green) This LED it up when the SDI 1 input is selected.
11
SYNC DVI 1 (yellow) This LE D lit up when a v alid input sync is detected for the applied SDI source.
12
SEL SDI 21 (green) This L ED it up w hen the SDI 2 input is selected.
13
SYNC DVI 2 (yellow) This LE D lit up when a v alid input sync is detected for the applied SDI source.
316 R5905312 HDF W SERIES 24/01/2013
