Branson 2000X - Page 111

2000X energy Power Supply Chapter 6: Operation
Instruction Manual Setting Primary Parameters
011-003-991 EN 6-19
2000X Power Supply Main Menu: Weld Setup (Energy Mode)
MAIN MENU
Pge1of6
Run Screen
Weld Setup
Save/Recall Presets
Print Menu
Diagnostics
System Information
System Configuration
WELD SETUP
Pg1of20
Weld Mode>
Energy
Weld Energy(J)=
30000
Hold Time(s)= 30.000
Ext U/S Delay =
Amplitude> STEP
Amplitude(%)=
Pretrigger> Off
Afterburst> Off
Energy Brake> Off
Digital UPS >
Post Weld Seek = Off
Frequency Offset> Off
Act Clr Out>
Cycle Aborts> Off
AMP STEP Pge1of5
Amplitude A(%)= 100
Amplitude B(%)= 100
Step @ T(s)= Off
Step @ E(J)= 65000
ACT CLR OUT Pg1of1
FREQ OFFSET
Pg1of1
Freq Offset(Hz)= +200
WELD MODE
Pg1of4
Time= Off
Energy= On
REJ LIMITS Pg1of13
Reset Required= On
+R Time(s)= 65000
-R Time(s)= 65000
+R Pk Power(%)= 100
SUSP LIMITS Pg1of13
Reset Required= On
+S Time(s)= 65000
-S Time(s)= 65000
+S Pk Power(%)= 100
