2000X energy Power Supply Chapter 6: Operation
Instruction Manual Setting Primary Parameters
011-003-991 EN 6-29
Setting Scrub Time
You can select the amount of time you want to elapse between detection of a ground con-
dition and the termination of ultrasonics.
NOTE
i
Your must have Ground Detect Cable EDP No. 100-246-630 installed to utilize the ground
detect feature. It connects from the MPS/GDS receptacle on the rear of the actuator to the
electrically isolated fixture/anvil.
Take this action… To get this result…
Press the Select key that corresponds to
Scrub Time(s).
Use the numeric keypad to enter the Scrub
Time (in seconds) that you want to use, or
press the same Select key repeatedly to
toggle between the minimum value (.001
second) and the maximum value (0.500
second) for Scrub Time.
WELD SETUP Pg1of20
Weld Mode> Gnd Detect
Scrub Time(s)= 0.500
Hold Time(s)= 30.000
Select
Select
Select
WELD SETUP Pg1of20
Weld Mode> Gnd Detect
Scrub Time(s)= 0.100
Hold Time(s)= 30.000
Select
Select
Select
