Chapter 6: Operation
Viewing System Information
6-90 011-003-991 EN
• PS Life: indicates the total number of cycles on the Power
Supply.
• Overloads: indicates the number of times the Power Sup-
ply has been overloaded.
• Gen Alarm: indicates the number of times the Power Sup-
ply has had general alarms.
• 20 kHz 1100 W: this line indicates the frequency and watt-
age of your Power Supply.
• P/S Version: indicates digital Power Supply software ver-
sion. (Currently not shown)
• P/S Presets: indicates Preset names and library name.
• Actuator: indicates the model actuator that is attached to
your Power Supply.
• Control Level: indicates the feature level of the controller
installed in your Power Supply.
• S/W Version: Indicates the software version.
• P/S S/N: indicates the serial number of the Power Supply.
• Welder Addr: Turn on to assign a unique trackable number
to a welder for data collection.
• Cyl Dia (in): indicates the diameter of the cylinder.
• Cyl Stroke (in): indicates the length of the stroke.
SYSTEM INFO Pg1of10
Calibration Data>
PS Life = xxxxx
Overloads = xxxxx
SYSTEM INFO Pg3of10
Gen Alarm = 0
20kHz 1100W
SYSTEM INFO Pg4of10
P/S Version = xx.xx
P/S Presets
Actuator = ae/HH
SYSTEM INFO Pg7of10
Control Level = ea
S/W Version = x.xx
P/S S/N = xxxxx
SYSTEM INFOPg9,10of10
Welder Addr = 100
Cyl Dia (in) = 3.000
Cyl Stroke (in) = 4.0
To Next Page
